SBH11-NBPC-D05-RA-BK
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SBH11-NBPC-D05-RA-BK |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | 10 Positions Header, Shrouded Connector 0.100" (2.54mm) Through Hole, Right Angle Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SBH11-NBPC-D05-RA-BK Price |  |
Technical Specifications of SBH11-NBPC-D05-RA-BK
| Datasheet |  SBH11-NBPC-D05-RA-BK datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Sullins Connector Solutions |
| Series | SBH11 |
| Packaging | Tray |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 10 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Contact Mating Length | - |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | Polarizing Key |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Color | Black |
