SWR120-NPEG-S15-RA-BG
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SWR120-NPEG-S15-RA-BG |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | 15 Positions Header, Shrouded Connector 0.049" (1.25mm) Through Hole, Right Angle Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SWR120-NPEG-S15-RA-BG Price |  |
Technical Specifications of SWR120-NPEG-S15-RA-BG
| Category | Connectors, Interconnects |
|---|---|
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Sullins-Connector-Solutions |
| Series | SWR120 |
| Packaging | Bulk |
| Contact Type | Blade Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 15 |
| Number of Positions Loaded | All |
| Pitch | 0.049" (1.25mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | - |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | Detent Lock |
| Features | - |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Beige |
