MDF7-17P-2.54DS(55)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MDF7-17P-2.54DS(55) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | 17 Positions Header, Unshrouded Connector 0.100" (2.54mm) Through Hole, Right Angle Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MDF7-17P-2.54DS(55) Price |  |
Technical Specifications of MDF7-17P-2.54DS(55)
| Datasheet |  MDF7-17P-2.54DS(55) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Hirose-Electric-Co-Ltd |
| Series | MDF7 |
| Packaging | Bulk |
| Contact Type | Male Pin |
| Connector Type | Header, Unshrouded |
| Number of Positions | 17 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | 0.292" (7.42mm) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Tin |
| Contact Finish Thickness | 39μin (1.00μm) |
| Color | Black |
