IL-Z-13PL-SMTYE
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | IL-Z-13PL-SMTYE |
|---|---|
| Manufacturer | JAE Electronics |
| Description | 13 Positions Header, Shrouded Connector 0.049" (1.25mm) Surface Mount, Right Angle Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| IL-Z-13PL-SMTYE Price |  |
Technical Specifications of IL-Z-13PL-SMTYE
| Datasheet |  IL-Z-13PL-SMTYE datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | JAE Electronics |
| Series | IL-Z |
| Packaging | Tray |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 13 |
| Number of Positions Loaded | All |
| Pitch | 0.049" (1.25mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | 0.108" (2.75mm) |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Beige |
