3429-2002
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 3429-2002 |
|---|---|
| Manufacturer | 3M |
| Description | 26 Positions Header, Shrouded Connector 0.100" (2.54mm) Through Hole Gold |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 3429-2002 Price |  |
Technical Specifications of 3429-2002
| Datasheet |  3429-2002 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | 3M |
| Series | 3000 |
| Packaging | Bulk |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 26 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Contact Mating Length | 0.240" (6.10mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | - |
| Features | Mounting Flange |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Color | Black |
