20-301550-10
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 20-301550-10 |
|---|---|
| Manufacturer | Aries Electronics |
| Description | IC Socket Adapter SOIC To PLCC Through Hole |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 20-301550-10 Price |  |
Technical Specifications of 20-301550-10
| Datasheet |  20-301550-10 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Sockets for ICs, Transistors - Adapters |
| Manufacturer | Aries Electronics |
| Series | Correct-A-Chip? 301550 |
| Convert From (Adapter End) | SOIC |
| Convert To (Adapter End) | PLCC |
| Number of Pins | 20 |
| Pitch - Mating | 0.050" (1.27mm) |
| Contact Finish - Mating | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Pitch - Post | 0.100" (2.54mm) |
| Contact Finish - Post | Tin-Lead |
| Housing Material | - |
| Board Material | FR4 Epoxy Glass |
| Termination Post Length | 0.030" (0.76mm) |
| Material Flammability Rating | - |
| Features | - |
| Current Rating | - |
| Operating Temperature | - |
| Contact Material - Mating | - |
| Contact Material - Post | Brass |
| Contact Finish Thickness - Mating | - |
| Contact Finish Thickness - Post | 200μin (5.08μm) |
