Technical Specifications of D2620-42
| Datasheet |  D2620-42 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Sockets for ICs, Transistors |
|---|
| Manufacturer | Harwin Inc. |
|---|
| Series | D26 |
|---|
| Packaging | Tube |
|---|
| Type | DIP, 0.3" (7.62mm) Row Spacing |
|---|
| Number of Positions or Pins (Grid) | 20 (2 x 10) |
|---|
| Pitch - Mating | 0.100" (2.54mm) |
|---|
| Contact Finish - Mating | Gold |
|---|
| Contact Finish Thickness - Mating | 10μin (0.25μm) |
|---|
| Contact Material - Mating | Beryllium Copper |
|---|
| Mounting Type | Through Hole |
|---|
| Features | Open Frame |
|---|
| Termination | Press-Fit |
|---|
| Pitch - Post | 0.100" (2.54mm) |
|---|
| Contact Finish - Post | Tin |
|---|
| Contact Finish Thickness - Post | 196.8μin (5.00μm) |
|---|
| Contact Material - Post | Brass |
|---|
| Housing Material | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Termination Post Length | 0.110" (2.78mm) |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Current Rating | 1A |
|---|
| Contact Resistance | 10 mOhm |
|---|
We can supply Harwin Inc. part# D2620-42. Use the request quote form to request D2620-42 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number D2620-42. The price and lead time for D2620-42 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# D2620-42. We look forward to doing business with you.
