H524505100J0G
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | H524505100J0G |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | 24 Position Terminal Block Plug, Male Pins 0.200" (5.08mm) 180° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| H524505100J0G Price |  |
Technical Specifications of H524505100J0G
| Datasheet |  H524505100J0G datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Amphenol FCI |
| Series | H5 |
| Packaging | Bulk |
| Type | Plug, Male Pins |
| Number of Positions | 24 |
| Positions Per Level | 24 |
| Number of Levels | 1 |
| Pitch | 0.200" (5.08mm) |
| Header Orientation | - |
| Plug Wire Entry | 180° |
| Termination Style | Screwless - Leg Spring, Push-In Spring |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | - |
| Voltage - IEC | - |
| Current - UL | 10A |
| Voltage - UL | 300V |
| Wire Gauge or Range - AWG | 12-26 AWG |
| Wire Gauge or Range - mm2 | - |
| Color | Green |
| Operating Temperature | -40°C ~ 115°C |
| Contact Mating Finish | Tin |
| Features | Mating Flange |
