KI13305200J0G
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | KI13305200J0G |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | 13 Position Terminal Block Plug Housing for Female Sockets 0.150" (3.81mm) 180° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| KI13305200J0G Price |  |
Technical Specifications of KI13305200J0G
| Datasheet |  KI13305200J0G datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Amphenol FCI |
| Series | KI |
| Packaging | Bulk |
| Type | Plug Housing for Female Sockets |
| Number of Positions | 13 |
| Positions Per Level | 13 |
| Number of Levels | 1 |
| Pitch | 0.150" (3.81mm) |
| Header Orientation | - |
| Plug Wire Entry | 180° |
| Termination Style | Crimp |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | - |
| Voltage - IEC | - |
| Current - UL | 8A |
| Voltage - UL | 160V |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm2 | 1-1.2mm2 |
| Color | Green |
| Operating Temperature | - |
| Contact Mating Finish | - |
| Features | Mating Flange |
