1932010000
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1932010000 |
|---|---|
| Manufacturer | Weidmuller |
| Description | 7 Position Terminal Block Plug, Blade Pins 0.300" (7.62mm) 180° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1932010000 Price |  |
Technical Specifications of 1932010000
| Category | Connectors, Interconnects |
|---|---|
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Weidmuller |
| Series | Omnimate SV |
| Packaging | Bulk |
| Type | Plug, Blade Pins |
| Number of Positions | 7 |
| Positions Per Level | 7 |
| Number of Levels | 1 |
| Pitch | 0.300" (7.62mm) |
| Header Orientation | - |
| Plug Wire Entry | 180° |
| Termination Style | Screw - Clamping Yoke (Tension Sleeve) |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | 41A |
| Voltage - IEC | 1000V |
| Current - UL | 42A |
| Voltage - UL | 600V |
| Wire Gauge or Range - AWG | 8-24 AWG |
| Wire Gauge or Range - mm2 | 0.2-6mm2 |
| Color | Black |
| Operating Temperature | -50°C ~ 125°C |
| Contact Mating Finish | Tin |
| Features | Mating Flange |
