0399400416
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0399400416 |
|---|---|
| Manufacturer | Molex, LLC |
| Description | 16 Position Terminal Block Plug, Barrier Strip 0.200" (5.08mm) 90° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 0399400416 Price |  |
Technical Specifications of 0399400416
| Datasheet |  0399400416 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Molex, LLC |
| Series | EuroMate? 39940 |
| Packaging | Bulk |
| Type | Plug, Barrier Strip |
| Number of Positions | 16 |
| Positions Per Level | 16 (Mate), 8 (Input) |
| Number of Levels | 1 (Mate), 2 (Input) |
| Pitch | 0.200" (5.08mm) |
| Header Orientation | - |
| Plug Wire Entry | 90° |
| Termination Style | Screw with Captive Plate |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | - |
| Voltage - IEC | - |
| Current - UL | 15A |
| Voltage - UL | 300V |
| Wire Gauge or Range - AWG | 12-22 AWG |
| Wire Gauge or Range - mm2 | 0.3-3.3mm2 |
| Color | Black |
| Operating Temperature | -40°C ~ 90°C |
| Contact Mating Finish | Tin |
| Features | Mating Flange |
