0397170005
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0397170005 |
|---|---|
| Manufacturer | Molex, LLC |
| Description | 5 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm) 180° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 0397170005 Price |  |
Technical Specifications of 0397170005
| Datasheet |  0397170005 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Molex, LLC |
| Series | 39717 |
| Packaging | Bulk |
| Type | Plug, Female Sockets |
| Number of Positions | 5 |
| Positions Per Level | 5 (Mate), 10 (Input) |
| Number of Levels | 1 (Mate), 2 (Input) |
| Pitch | 0.200" (5.08mm) |
| Header Orientation | - |
| Plug Wire Entry | 180° |
| Termination Style | Screw |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | - |
| Voltage - IEC | - |
| Current - UL | 12A |
| Voltage - UL | 250V |
| Wire Gauge or Range - AWG | 12-24 AWG |
| Wire Gauge or Range - mm2 | - |
| Color | Green |
| Operating Temperature | -40°C ~ 105°C |
| Contact Mating Finish | Tin |
| Features | Retention Latches (Non-Wire Side) |
