1778777
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1778777 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | 3 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.098" (2.50mm) 90°, Right Angle Surface Mount |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1778777 Price |  |
Technical Specifications of 1778777
| Category | Connectors, Interconnects |
|---|---|
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Phoenix Contact |
| Series | COMBICON PTSM |
| Packaging | Tape & Reel (TR) |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Number of Positions | 3 |
| Positions Per Level | 3 |
| Number of Levels | 1 |
| Pitch | 0.098" (2.50mm) |
| Header Orientation | 90°, Right Angle |
| Plug Wire Entry | - |
| Termination Style | Solder |
| Mounting Type | Surface Mount |
| Current - IEC | 6A |
| Voltage - IEC | 160V |
| Current - UL | - |
| Voltage - UL | - |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm2 | - |
| Color | Black |
| Operating Temperature | - |
| Contact Mating Finish | Tin |
| Features | Board Guide, Pick and Place Cap, Solder Retention |
