3060034
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 3060034 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | 1 Position Terminal Block Plug, Female Sockets 180° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 3060034 Price |  |
Technical Specifications of 3060034
| Category | Connectors, Interconnects |
|---|---|
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Phoenix Contact |
| Series | CLIPLINE COMBI UP |
| Packaging | Bulk |
| Type | Plug, Female Sockets |
| Number of Positions | 1 |
| Positions Per Level | 1 |
| Number of Levels | 1 |
| Pitch | - |
| Header Orientation | - |
| Plug Wire Entry | 180° |
| Termination Style | Screw |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | 32A |
| Voltage - IEC | 800V |
| Current - UL | 30A |
| Voltage - UL | 600V |
| Wire Gauge or Range - AWG | 10-26 AWG |
| Wire Gauge or Range - mm2 | 0.2-6mm2 |
| Color | Blue |
| Operating Temperature | - |
| Contact Mating Finish | - |
| Features | Interlocking (Side) |
