ELFK19210
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ELFK19210 |
|---|---|
| Manufacturer | Amphenol PCD |
| Description | 19 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm) 45° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ELFK19210 Price |  |
Technical Specifications of ELFK19210
| Datasheet |  ELFK19210 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Amphenol PCD |
| Series | ELFK |
| Packaging | Tray |
| Type | Plug, Female Sockets |
| Number of Positions | 19 |
| Positions Per Level | 19 |
| Number of Levels | 1 |
| Pitch | 0.200" (5.08mm) |
| Header Orientation | - |
| Plug Wire Entry | 45° |
| Termination Style | Screw - Rising Cage Clamp |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | - |
| Voltage - IEC | - |
| Current - UL | 15A |
| Voltage - UL | 300V |
| Wire Gauge or Range - AWG | 12 AWG, 14-26 AWG |
| Wire Gauge or Range - mm2 | - |
| Color | Black |
| Operating Temperature | 105°C |
| Contact Mating Finish | Nickel |
| Features | Retention Latches (Non-Wire Side) |
