EDSTL130/09
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | EDSTL130/09 |
|---|---|
| Manufacturer | On Shore Technology Inc. |
| Description | 9 Position Terminal Block Header, Male Pins, Unshrouded 0.197" (5.00mm) Vertical Through Hole |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| EDSTL130/09 Price |  |
Technical Specifications of EDSTL130/09
| Datasheet |  EDSTL130/09 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | On Shore Technology Inc. |
| Series | EDSTL130 |
| Packaging | Bulk |
| Type | Header, Male Pins, Unshrouded |
| Number of Positions | 9 |
| Positions Per Level | 9 |
| Number of Levels | 1 |
| Pitch | 0.197" (5.00mm) |
| Header Orientation | Vertical |
| Plug Wire Entry | - |
| Termination Style | Solder |
| Mounting Type | Through Hole |
| Current - IEC | - |
| Voltage - IEC | - |
| Current - UL | 10A |
| Voltage - UL | 300V |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm2 | - |
| Color | Black |
| Operating Temperature | -30°C ~ 105°C |
| Contact Mating Finish | - |
| Features | - |
