1157320000
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1157320000 |
|---|---|
| Manufacturer | Weidmuller |
| Description | 3 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.400" (10.16mm) 90°, Right Angle, Under Board Through Hole |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1157320000 Price |  |
Technical Specifications of 1157320000
| Category | Connectors, Interconnects |
|---|---|
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Weidmuller |
| Series | Omnimate SU |
| Packaging | Bulk |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Number of Positions | 3 |
| Positions Per Level | 3 |
| Number of Levels | 1 |
| Pitch | 0.400" (10.16mm) |
| Header Orientation | 90°, Right Angle, Under Board |
| Plug Wire Entry | - |
| Termination Style | Solder |
| Mounting Type | Through Hole |
| Current - IEC | 78.3A |
| Voltage - IEC | 1000V |
| Current - UL | 60A |
| Voltage - UL | 300V |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm2 | - |
| Color | Black |
| Operating Temperature | -50°C ~ 100°C |
| Contact Mating Finish | Silver |
| Features | Latch Holder |
