1913976
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1913976 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | 7 Position Terminal Block Plug for Unshrouded Header 0.138" (3.50mm) 90° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1913976 Price |  |
Technical Specifications of 1913976
| Datasheet |  1913976 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | Phoenix Contact |
| Series | COMBICON FK-MPT |
| Packaging | Bulk |
| Type | Plug for Unshrouded Header |
| Number of Positions | 7 |
| Positions Per Level | 7 |
| Number of Levels | 1 |
| Pitch | 0.138" (3.50mm) |
| Header Orientation | - |
| Plug Wire Entry | 90° |
| Termination Style | Screwless - Spring Cage, Tension Clamp |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | 4A |
| Voltage - IEC | 250V |
| Current - UL | 4A |
| Voltage - UL | 300V |
| Wire Gauge or Range - AWG | 20-28 AWG |
| Wire Gauge or Range - mm2 | 0.12-0.5mm2 |
| Color | Green |
| Operating Temperature | - |
| Contact Mating Finish | Tin |
| Features | - |
