Technical Specifications of 1-1546227-2
| Datasheet |  1-1546227-2 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminal Blocks - Wire to Board |
|---|
| Manufacturer | TE Connectivity AMP Connectors |
|---|
| Series | Buchanan |
|---|
| Packaging | Bulk |
|---|
| Number of Levels | 1 |
|---|
| Positions Per Level | 12 |
|---|
| Pitch | 0.138" (3.50mm) |
|---|
| Mating Orientation | Horizontal with Board |
|---|
| Current | 12A |
|---|
| Voltage | 300V |
|---|
| Wire Gauge | 14-30 AWG |
|---|
| Mounting Type | Through Hole |
|---|
| Wire Termination | Screw - Rising Cage Clamp |
|---|
| Features | Interlocking (Side) |
|---|
| Color | Blue |
|---|
| Operating Temperature | -40°C ~ 105°C |
|---|
| Housing Material | Polyamide (PA66), Nylon 6/6 |
|---|
| Contact Material - Plating | Brass - Tin Plated |
|---|
| Clamp Material - Plating | Brass - Nickel Plated |
|---|
| Screw Material - Plating | Brass - Nickel Plated |
|---|
| Torque - Screw | 0.25 Nm (2.2 Lb-In) |
|---|
| Screw Thread | M3 |
|---|
We can supply TE Connectivity AMP Connectors part# 1-1546227-2. Use the request quote form to request 1-1546227-2 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 1-1546227-2. The price and lead time for 1-1546227-2 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 1-1546227-2. We look forward to doing business with you.
