Technical Specifications of LCC2-56BWH-Q
| Datasheet |  LCC2-56BWH-Q datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Rectangular Connectors |
|---|
| Manufacturer | Panduit Corp |
|---|
| Series | Pan-Lug? |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Rectangular Tongue |
|---|
| Stud/Tab Size | 5/16 Stud |
|---|
| Terminal Style | Two Stud Holes |
|---|
| Tab Thickness | 0.100" (2.54mm) |
|---|
| Length - Overall | - |
|---|
| Width - Outer Edges | 0.660" (16.76mm) |
|---|
| Mounting Type | Free Hanging (In-Line), 45° Angle |
|---|
| Termination | Crimp, Barrel |
|---|
| Wire Gauge | 2 AWG |
|---|
| Insulation | Non-Insulated |
|---|
| Features | - |
|---|
| Color | Brown |
|---|
| Contact Finish | Electro-Tin |
|---|
| Contact Material | Copper |
|---|
| Diameter - Barrel ID | 0.310" (7.87mm) |
|---|
| Diameter - Barrel OD | 0.420" (10.67mm) |
|---|
| Diameter - Ring ID | 0.340" (8.64mm) |
|---|
We can supply Panduit Corp part# LCC2-56BWH-Q. Use the request quote form to request LCC2-56BWH-Q pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LCC2-56BWH-Q. The price and lead time for LCC2-56BWH-Q depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# LCC2-56BWH-Q. We look forward to doing business with you.
