Technical Specifications of PV4-56R-E
| Datasheet |  PV4-56R-E datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Ring Connectors |
|---|
| Manufacturer | Panduit Corp |
|---|
| Series | Pan-Term? |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Flat Sided |
|---|
| Stud/Tab Size | 5/16 Stud |
|---|
| Thickness | 0.050" (1.27mm) |
|---|
| Width - Outer Edges | 0.680" (17.27mm) |
|---|
| Length - Overall | 1.950" (49.50mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Wire Gauge | 4 AWG |
|---|
| Insulation | Insulated |
|---|
| Features | Brazed Seam |
|---|
| Color | Yellow |
|---|
| Contact Material | Copper |
|---|
| Contact Finish | Tin |
|---|
| Insulation Diameter | 0.450" (11.43mm) |
|---|
| Material - Insulation | Vinyl |
|---|
We can supply Panduit Corp part# PV4-56R-E. Use the request quote form to request PV4-56R-E pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PV4-56R-E. The price and lead time for PV4-56R-E depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PV4-56R-E. We look forward to doing business with you.
