Technical Specifications of PH14-10R-Q
| Datasheet |  PH14-10R-Q datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Ring Connectors |
|---|
| Manufacturer | Panduit Corp |
|---|
| Series | Pan-Term? |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Circular |
|---|
| Stud/Tab Size | 10 Stud |
|---|
| Thickness | - |
|---|
| Width - Outer Edges | 0.320" (8.13mm) |
|---|
| Length - Overall | 1.050" (26.67mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Wire Gauge | 14-16 AWG |
|---|
| Insulation | Insulated with Heat Shrink |
|---|
| Features | Brazed Seam |
|---|
| Color | Blue |
|---|
| Contact Material | Copper |
|---|
| Contact Finish | Tin |
|---|
| Insulation Diameter | 0.190" (4.83mm) |
|---|
| Material - Insulation | Polyolefin |
|---|
We can supply Panduit Corp part# PH14-10R-Q. Use the request quote form to request PH14-10R-Q pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PH14-10R-Q. The price and lead time for PH14-10R-Q depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PH14-10R-Q. We look forward to doing business with you.
