Technical Specifications of SB05-03Q-TL-E
| Datasheet |  SB05-03Q-TL-E datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Single |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Type | Schottky |
|---|
| Voltage - DC Reverse (Vr) (Max) | 30V |
|---|
| Current - Average Rectified (Io) | 500mA |
|---|
| Voltage - Forward (Vf) (Max) @ If | 550mV @ 500mA |
|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
|---|
| Reverse Recovery Time (trr) | 10ns |
|---|
| Current - Reverse Leakage @ Vr | 30μA @ 15V |
|---|
| Capacitance @ Vr, F | 16pF @ 10V, 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SC-70, SOT-323 |
|---|
| Supplier Device Package | 3-MCP |
|---|
| Operating Temperature - Junction | -55°C ~ 125°C |
|---|
We can supply ON Semiconductor part# SB05-03Q-TL-E. Use the request quote form to request SB05-03Q-TL-E pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SB05-03Q-TL-E. The price and lead time for SB05-03Q-TL-E depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SB05-03Q-TL-E. We look forward to doing business with you.
