Technical Specifications of SD560CTR
| Datasheet |  SD560CTR datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Single |
|---|
| Manufacturer | SMC Diode Solutions |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Type | Standard |
|---|
| Voltage - DC Reverse (Vr) (Max) | 60V |
|---|
| Current - Average Rectified (Io) | 5A |
|---|
| Voltage - Forward (Vf) (Max) @ If | 750mV @ 5A |
|---|
| Speed | Standard Recovery >500ns, > 200mA (Io) |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Current - Reverse Leakage @ Vr | 2mA @ 60V |
|---|
| Capacitance @ Vr, F | 550pF @ 4V, 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | DO-214AB, SMC |
|---|
| Supplier Device Package | SMC |
|---|
| Operating Temperature - Junction | -55°C ~ 125°C |
|---|
We can supply SMC Diode Solutions part# SD560CTR. Use the request quote form to request SD560CTR pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SD560CTR. The price and lead time for SD560CTR depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SD560CTR. We look forward to doing business with you.
