1SV322(TPH3,F)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1SV322(TPH3,F) |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | DIODE VARACTOR 10V USC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1SV322(TPH3,F) Price |  |
Technical Specifications of 1SV322(TPH3,F)
| Datasheet |  1SV322(TPH3,F) datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Diodes - Variable Capacitance (Varicaps, Varactors) |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Capacitance @ Vr, F | 7.1pF @ 4V, 1MHz |
| Capacitance Ratio | 4.3 |
| Capacitance Ratio Condition | C1/C4 |
| Voltage - Peak Reverse (Max) | 10V |
| Diode Type | Single |
| Q @ Vr, F | - |
| Mounting Type | Surface Mount |
| Package / Case | SC-76, SOD-323 |
| Supplier Device Package | USC |
