Technical Specifications of L314F
| Datasheet |  L314F datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Thyristors - SCRs - Modules |
|---|
| Manufacturer | Crydom Co. |
|---|
| Series | - |
|---|
| Packaging | Bulk |
|---|
| Structure | Bridge, Single Phase - SCRs/Diodes (Layout 1) |
|---|
| Number of SCRs, Diodes | 2 SCRs, 2 Diodes |
|---|
| Voltage - Off State | 1200V |
|---|
| Current - Gate Trigger (Igt) (Max) | 100mA |
|---|
| Current - On State (It (AV)) (Max) | - |
|---|
| Current - On State (It (RMS)) (Max) | 15A (DC) |
|---|
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 2250A @ 60Hz |
|---|
| Current - Hold (Ih) (Max) | - |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Module |
|---|
We can supply Crydom Co. part# L314F. Use the request quote form to request L314F pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number L314F. The price and lead time for L314F depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# L314F. We look forward to doing business with you.
