Technical Specifications of MCR69-2G
| Datasheet |  MCR69-2G datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Thyristors - SCRs |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Bulk |
|---|
| Voltage - Off State | 50V |
|---|
| Voltage - Gate Trigger (Vgt) (Max) | 1.5V |
|---|
| Current - Gate Trigger (Igt) (Max) | 30mA |
|---|
| Voltage - On State (Vtm) (Max) | 1.8V |
|---|
| Current - On State (It (AV)) (Max) | 16A |
|---|
| Current - On State (It (RMS)) (Max) | 25A |
|---|
| Current - Hold (Ih) (Max) | 50mA |
|---|
| Current - Off State (Max) | 10μA |
|---|
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 300A @ 60Hz |
|---|
| SCR Type | Standard Recovery |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-220-3 |
|---|
| Supplier Device Package | TO-220AB |
|---|
We can supply ON Semiconductor part# MCR69-2G. Use the request quote form to request MCR69-2G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MCR69-2G. The price and lead time for MCR69-2G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MCR69-2G. We look forward to doing business with you.
