Technical Specifications of TS1220-700B
| Datasheet |  TS1220-700B datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Thyristors - SCRs |
|---|
| Manufacturer | STMicroelectronics |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| Voltage - Off State | 700V |
|---|
| Voltage - Gate Trigger (Vgt) (Max) | 800mV |
|---|
| Current - Gate Trigger (Igt) (Max) | 200μA |
|---|
| Voltage - On State (Vtm) (Max) | 1.6V |
|---|
| Current - On State (It (AV)) (Max) | 8A |
|---|
| Current - On State (It (RMS)) (Max) | 12A |
|---|
| Current - Hold (Ih) (Max) | 5mA |
|---|
| Current - Off State (Max) | 5μA |
|---|
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 110A, 115A |
|---|
| SCR Type | Sensitive Gate |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
|---|
| Supplier Device Package | D-Pak |
|---|
We can supply STMicroelectronics part# TS1220-700B. Use the request quote form to request TS1220-700B pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TS1220-700B. The price and lead time for TS1220-700B depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TS1220-700B. We look forward to doing business with you.
