EMG2DXV5T1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | EMG2DXV5T1 |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | TRANS 2NPN PREBIAS 0.23W SOT553 |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| EMG2DXV5T1 Price |  |
Technical Specifications of EMG2DXV5T1
| Datasheet |  EMG2DXV5T1 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Arrays, Pre-Biased |
| Manufacturer | ON Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | 2 NPN - Pre-Biased (Dual) |
| Current - Collector (Ic) (Max) | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 47k |
| Resistor - Emitter Base (R2) (Ohms) | 47k |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 80 @ 5mA, 10V |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 300μA, 10mA |
| Current - Collector Cutoff (Max) | 500nA |
| Frequency - Transition | - |
| Power - Max | 230mW |
| Mounting Type | Surface Mount |
| Package / Case | SOT-553 |
| Supplier Device Package | SOT-553 |
