PQMD3Z
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | PQMD3Z |
---|---|
Manufacturer | NXP Semiconductors |
Description | TRANS NPN/PNP RET 6DFN |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
PQMD3Z Price | ![]() |
Technical Specifications of PQMD3Z
Datasheet | ![]() |
---|---|
Category | Discrete Semiconductor Products |
Family | Transistors - Bipolar (BJT) - Arrays, Pre-Biased |
Manufacturer | NXP Semiconductors |
Series | Automotive, AEC-Q101 |
Packaging | Tape & Reel (TR) |
Transistor Type | 1 NPN, 1 PNP - Pre-Biased (Dual) |
Current - Collector (Ic) (Max) | 100mA |
Voltage - Collector Emitter Breakdown (Max) | 50V |
Resistor - Base (R1) (Ohms) | 10k |
Resistor - Emitter Base (R2) (Ohms) | 10k |
DC Current Gain (hFE) (Min) @ Ic, Vce | 30 @ 5mA, 5V |
Vce Saturation (Max) @ Ib, Ic | 150mV @ 500μA, 10mA |
Current - Collector Cutoff (Max) | 1μA |
Frequency - Transition | 230MHz, 180MHz |
Power - Max | 230mW |
Mounting Type | Surface Mount |
Package / Case | 6-XFDFN Exposed Pad |
Supplier Device Package | DFN1010B-6 |
