UMG3NTR
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | UMG3NTR |
|---|---|
| Manufacturer | Rohm Semiconductor |
| Description | TRANS 2NPN PREBIAS 0.15W UMT5 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| UMG3NTR Price |  |
Technical Specifications of UMG3NTR
| Datasheet |  UMG3NTR datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Arrays, Pre-Biased |
| Manufacturer | Rohm Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | 2 NPN - Pre-Biased (Dual) |
| Current - Collector (Ic) (Max) | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 4.7k |
| Resistor - Emitter Base (R2) (Ohms) | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 1mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 150mV @ 250μA, 5mA |
| Current - Collector Cutoff (Max) | - |
| Frequency - Transition | 250MHz |
| Power - Max | 150mW |
| Mounting Type | Surface Mount |
| Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
| Supplier Device Package | UMT5 |
