Technical Specifications of ULN2803ADWG4
| Datasheet |  ULN2803ADWG4 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - Bipolar (BJT) - Arrays |
|---|
| Manufacturer | Texas Instruments |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| Transistor Type | 8 NPN Darlington |
|---|
| Current - Collector (Ic) (Max) | 500mA |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 50V |
|---|
| Vce Saturation (Max) @ Ib, Ic | 1.6V @ 500μA, 350mA |
|---|
| Current - Collector Cutoff (Max) | - |
|---|
| DC Current Gain (hFE) (Min) @ Ic, Vce | - |
|---|
| Power - Max | - |
|---|
| Frequency - Transition | - |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 18-SOIC (0.295", 7.50mm Width) |
|---|
| Supplier Device Package | 18-SOIC |
|---|
We can supply Texas Instruments part# ULN2803ADWG4. Use the request quote form to request ULN2803ADWG4 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ULN2803ADWG4. The price and lead time for ULN2803ADWG4 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ULN2803ADWG4. We look forward to doing business with you.
