DDTC113TLP-7
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DDTC113TLP-7 |
|---|---|
| Manufacturer | Diodes Incorporated |
| Description | TRANS PREBIAS NPN 250MW 3DFN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DDTC113TLP-7 Price |  |
Technical Specifications of DDTC113TLP-7
| Datasheet |  DDTC113TLP-7 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Single, Pre-Biased |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | NPN - Pre-Biased |
| Current - Collector (Ic) (Max) | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 1k |
| Resistor - Emitter Base (R2) (Ohms) | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 1mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 2.5mA, 50mA |
| Current - Collector Cutoff (Max) | 500nA (ICBO) |
| Frequency - Transition | 250MHz |
| Power - Max | 250mW |
| Mounting Type | Surface Mount |
| Package / Case | 3-UFDFN |
| Supplier Device Package | 3-DFN1006 (1.0x0.6) |
