BCR158E6327HTSA1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | BCR158E6327HTSA1 |
|---|---|
| Manufacturer | Infineon Technologies |
| Description | TRANS PREBIAS PNP 0.2W SOT23-3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| BCR158E6327HTSA1 Price |  |
Technical Specifications of BCR158E6327HTSA1
| Datasheet |  BCR158E6327HTSA1 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Single, Pre-Biased |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | PNP - Pre-Biased |
| Current - Collector (Ic) (Max) | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 2.2k |
| Resistor - Emitter Base (R2) (Ohms) | 47k |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 70 @ 5mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 500μA, 10mA |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| Frequency - Transition | 200MHz |
| Power - Max | 200mW |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | PG-SOT23-3 |
