TPC8208(TE12L,Q,M)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | TPC8208(TE12L,Q,M) |
---|---|
Manufacturer | Toshiba Semiconductor and Storage |
Description | MOSFET 2N-CH 20V 5A SOP8 |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
TPC8208(TE12L,Q,M) Price | ![]() |
Technical Specifications of TPC8208(TE12L,Q,M)
Category | Discrete Semiconductor Products |
---|---|
Family | Transistors - FETs, MOSFETs - Arrays |
Manufacturer | Toshiba Semiconductor and Storage |
Series | - |
Packaging | Tape & Reel (TR) |
FET Type | 2 N-Channel (Dual) |
FET Feature | Logic Level Gate |
Drain to Source Voltage (Vdss) | 20V |
Current - Continuous Drain (Id) @ 25°C | 5A |
Rds On (Max) @ Id, Vgs | 50 mOhm @ 2.5A, 4V |
Vgs(th) (Max) @ Id | 1.2V @ 200μA |
Gate Charge (Qg) @ Vgs | 9.5nC @ 5V |
Input Capacitance (Ciss) @ Vds | 780pF @ 10V |
Power - Max | 450mW |
Operating Temperature | 150°C (TJ) |
Mounting Type | Surface Mount |
Package / Case | 8-SOIC (0.173", 4.40mm Width) |
Supplier Device Package | 8-SOP (5.5x6.0) |
