Technical Specifications of AOD609
| Datasheet |  AOD609 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | Alpha & Omega Semiconductor Inc. |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | N and P-Channel, Common Drain |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 40V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 12A |
|---|
| Rds On (Max) @ Id, Vgs | 30 mOhm @ 12A, 10V |
|---|
| Vgs(th) (Max) @ Id | 3V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 10.8nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 650pF @ 20V |
|---|
| Power - Max | 2W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-252-5, DPak (4 Leads + Tab), TO-252AD |
|---|
| Supplier Device Package | TO-252-4L |
|---|
We can supply Alpha & Omega Semiconductor Inc. part# AOD609. Use the request quote form to request AOD609 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AOD609. The price and lead time for AOD609 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# AOD609. We look forward to doing business with you.
