Technical Specifications of IRF7755GTRPBF
| Datasheet |  IRF7755GTRPBF datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | HEXFET? |
|---|
| Packaging | Cut Tape (CT) |
|---|
| FET Type | 2 P-Channel (Dual) |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 20V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 3.9A |
|---|
| Rds On (Max) @ Id, Vgs | 51 mOhm @ 3.7A, 4.5V |
|---|
| Vgs(th) (Max) @ Id | 1.2V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 17nC @ 4.5V |
|---|
| Input Capacitance (Ciss) @ Vds | 1090pF @ 15V |
|---|
| Power - Max | 1W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-TSSOP (0.173", 4.40mm Width) |
|---|
| Supplier Device Package | 8-TSSOP |
|---|
We can supply Infineon Technologies part# IRF7755GTRPBF. Use the request quote form to request IRF7755GTRPBF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IRF7755GTRPBF. The price and lead time for IRF7755GTRPBF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IRF7755GTRPBF. We look forward to doing business with you.
