Technical Specifications of BSC072N03LD G
| Datasheet |  BSC072N03LD G datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | OptiMOS? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | 2 N-Channel (Dual) |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 30V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 11.5A |
|---|
| Rds On (Max) @ Id, Vgs | 7.2 mOhm @ 20A, 10V |
|---|
| Vgs(th) (Max) @ Id | 2.2V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 41nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 3500pF @ 15V |
|---|
| Power - Max | 57W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-PowerVDFN |
|---|
| Supplier Device Package | PG-TDSON-8 (5.15x6.15) |
|---|
We can supply Infineon Technologies part# BSC072N03LD G. Use the request quote form to request BSC072N03LD G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number BSC072N03LD G. The price and lead time for BSC072N03LD G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# BSC072N03LD G. We look forward to doing business with you.
