Technical Specifications of DMG6301UDW-13
| Datasheet |  DMG6301UDW-13 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | Diodes Incorporated |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | 2 N-Channel (Dual) |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 25V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 240mA |
|---|
| Rds On (Max) @ Id, Vgs | 4 Ohm @ 400mA, 4.5V |
|---|
| Vgs(th) (Max) @ Id | 1.5V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 0.36nC @ 4.5V |
|---|
| Input Capacitance (Ciss) @ Vds | 27.9pF @ 10V |
|---|
| Power - Max | 300mW |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
|---|
| Supplier Device Package | SOT-363 |
|---|
We can supply Diodes Incorporated part# DMG6301UDW-13. Use the request quote form to request DMG6301UDW-13 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number DMG6301UDW-13. The price and lead time for DMG6301UDW-13 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# DMG6301UDW-13. We look forward to doing business with you.
