Technical Specifications of ECH8661-TL-H
| Datasheet |  ECH8661-TL-H datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | N and P-Channel |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 30V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 7A, 5.5A |
|---|
| Rds On (Max) @ Id, Vgs | 24 mOhm @ 3.5A, 10V |
|---|
| Vgs(th) (Max) @ Id | - |
|---|
| Gate Charge (Qg) @ Vgs | 11.8nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 710pF @ 10V |
|---|
| Power - Max | 1.5W |
|---|
| Operating Temperature | 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-SMD, Flat Lead |
|---|
| Supplier Device Package | 8-ECH |
|---|
We can supply ON Semiconductor part# ECH8661-TL-H. Use the request quote form to request ECH8661-TL-H pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ECH8661-TL-H. The price and lead time for ECH8661-TL-H depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ECH8661-TL-H. We look forward to doing business with you.
