Technical Specifications of TPC8223-H,LQ(S
| Datasheet |  TPC8223-H,LQ(S datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | Toshiba Semiconductor and Storage |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | 2 N-Channel (Dual) |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 30V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 9A |
|---|
| Rds On (Max) @ Id, Vgs | 17 mOhm @ 4.5A, 10V |
|---|
| Vgs(th) (Max) @ Id | 2.3V @ 100μA |
|---|
| Gate Charge (Qg) @ Vgs | 17nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 1190pF @ 10V |
|---|
| Power - Max | 450mW |
|---|
| Operating Temperature | 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
|---|
| Supplier Device Package | 8-SOP |
|---|
We can supply Toshiba Semiconductor and Storage part# TPC8223-H,LQ(S. Use the request quote form to request TPC8223-H,LQ(S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TPC8223-H,LQ(S. The price and lead time for TPC8223-H,LQ(S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TPC8223-H,LQ(S. We look forward to doing business with you.
