Technical Specifications of APTC80A10SCTG
| Datasheet |  APTC80A10SCTG datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | - |
|---|
| Packaging | Bulk |
|---|
| FET Type | 2 N-Channel (Half Bridge) |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 800V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 42A |
|---|
| Rds On (Max) @ Id, Vgs | 100 mOhm @ 21A, 10V |
|---|
| Vgs(th) (Max) @ Id | 3.9V @ 3mA |
|---|
| Gate Charge (Qg) @ Vgs | 273nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 6761pF @ 25V |
|---|
| Power - Max | 416W |
|---|
| Operating Temperature | -40°C ~ 150°C (TJ) |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | SP4 |
|---|
| Supplier Device Package | SP4 |
|---|
We can supply Microsemi Corporation part# APTC80A10SCTG. Use the request quote form to request APTC80A10SCTG pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APTC80A10SCTG. The price and lead time for APTC80A10SCTG depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APTC80A10SCTG. We look forward to doing business with you.
