Technical Specifications of NDS9947
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | PowerTrench? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | 2 P-Channel (Dual) |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 20V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 3.5A |
|---|
| Rds On (Max) @ Id, Vgs | 100 mOhm @ 3.5A, 10V |
|---|
| Vgs(th) (Max) @ Id | 3V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 13nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 542pF @ 10V |
|---|
| Power - Max | 900mW |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
|---|
| Supplier Device Package | 8-SO |
|---|
We can supply Fairchild Semiconductor part# NDS9947. Use the request quote form to request NDS9947 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number NDS9947. The price and lead time for NDS9947 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# NDS9947. We look forward to doing business with you.
