Technical Specifications of APT23F60S
| Datasheet |  APT23F60S datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | POWER MOS 8? |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, FREDFET |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 600V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 24A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 290 mOhm @ 11A, 10V |
|---|
| Vgs(th) (Max) @ Id | 5V @ 1mA |
|---|
| Gate Charge (Qg) @ Vgs | 110nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 4415pF @ 25V |
|---|
| Power - Max | 415W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-268-3, D3Pak (2 Leads + Tab), TO-268AA |
|---|
| Supplier Device Package | D3Pak |
|---|
We can supply Microsemi Corporation part# APT23F60S. Use the request quote form to request APT23F60S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APT23F60S. The price and lead time for APT23F60S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APT23F60S. We look forward to doing business with you.
