TPC6011(TE85L,F,M)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TPC6011(TE85L,F,M) |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET N-CH 30V 6A VS6 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TPC6011(TE85L,F,M) Price |  |
Technical Specifications of TPC6011(TE85L,F,M)
| Datasheet |  TPC6011(TE85L,F,M) datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 6A (Ta) |
| Rds On (Max) @ Id, Vgs | 20 mOhm @ 3A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Gate Charge (Qg) @ Vgs | 14nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 640pF @ 10V |
| Power - Max | - |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Supplier Device Package | VS-6 (2.9x2.8) |
