IPD26N06S2L35ATMA2
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | IPD26N06S2L35ATMA2 |
|---|---|
| Manufacturer | Infineon Technologies |
| Description | MOSFET N-CH 55V 30A TO252-3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| IPD26N06S2L35ATMA2 Price |  |
Technical Specifications of IPD26N06S2L35ATMA2
| Datasheet |  IPD26N06S2L35ATMA2 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Infineon Technologies |
| Series | OptiMOS? |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 55V |
| Current - Continuous Drain (Id) @ 25°C | 30A (Tc) |
| Rds On (Max) @ Id, Vgs | 35 mOhm @ 13A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 26μA |
| Gate Charge (Qg) @ Vgs | 24nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 621pF @ 25V |
| Power - Max | 68W |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Supplier Device Package | PG-TO252-3-11 |
