IPD50N03S4L06ATMA1

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | IPD50N03S4L06ATMA1 |
---|---|
Manufacturer | Infineon Technologies |
Description | MOSFET N-CH 30V 50A TO252-3 |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
IPD50N03S4L06ATMA1 Price | ![]() |
Technical Specifications of IPD50N03S4L06ATMA1
Datasheet | ![]() |
---|---|
Category | Discrete Semiconductor Products |
Family | Transistors - FETs, MOSFETs - Single |
Manufacturer | Infineon Technologies |
Series | Automotive, AEC-Q101, OptiMOS? |
Packaging | Tape & Reel (TR) |
FET Type | MOSFET N-Channel, Metal Oxide |
FET Feature | Standard |
Drain to Source Voltage (Vdss) | 30V |
Current - Continuous Drain (Id) @ 25°C | 50A (Tc) |
Rds On (Max) @ Id, Vgs | 5.5 mOhm @ 50A, 10V |
Vgs(th) (Max) @ Id | 2.2V @ 20μA |
Gate Charge (Qg) @ Vgs | 31nC @ 10V |
Input Capacitance (Ciss) @ Vds | 2330pF @ 25V |
Power - Max | 56W |
Operating Temperature | -55°C ~ 175°C (TJ) |
Mounting Type | Surface Mount |
Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
Supplier Device Package | PG-TO252-3-11 |
