Technical Specifications of TPS1100D
| Datasheet |  TPS1100D datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Texas Instruments |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET P-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 15V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 1.6A (Ta) |
|---|
| Rds On (Max) @ Id, Vgs | 180 mOhm @ 1.5A, 10V |
|---|
| Vgs(th) (Max) @ Id | 1.5V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 5.45nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | - |
|---|
| Power - Max | 791mW |
|---|
| Operating Temperature | -40°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
|---|
| Supplier Device Package | 8-SOIC |
|---|
We can supply Texas Instruments part# TPS1100D. Use the request quote form to request TPS1100D pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TPS1100D. The price and lead time for TPS1100D depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TPS1100D. We look forward to doing business with you.
