Technical Specifications of FDA20N50_F109
| Datasheet |  FDA20N50_F109 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | UniFET? |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 500V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 22A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 230 mOhm @ 11A, 10V |
|---|
| Vgs(th) (Max) @ Id | 5V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 59.5nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 3120pF @ 25V |
|---|
| Power - Max | 280W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-3P-3, SC-65-3 |
|---|
| Supplier Device Package | TO-3PN |
|---|
We can supply Fairchild Semiconductor part# FDA20N50_F109. Use the request quote form to request FDA20N50_F109 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FDA20N50_F109. The price and lead time for FDA20N50_F109 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FDA20N50_F109. We look forward to doing business with you.
