Technical Specifications of CSD23381F4
| Datasheet |  CSD23381F4 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Texas Instruments |
|---|
| Series | NexFET? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET P-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 12V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 2.3A (Ta) |
|---|
| Rds On (Max) @ Id, Vgs | 175 mOhm @ 500mA, 4.5V |
|---|
| Vgs(th) (Max) @ Id | 1.2V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 1.14nC @ 4.5V |
|---|
| Input Capacitance (Ciss) @ Vds | 236pF @ 6V |
|---|
| Power - Max | 500mW |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 3-XFDFN |
|---|
| Supplier Device Package | 3-PICOSTAR |
|---|
We can supply Texas Instruments part# CSD23381F4. Use the request quote form to request CSD23381F4 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CSD23381F4. The price and lead time for CSD23381F4 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CSD23381F4. We look forward to doing business with you.
